High Sensitive Shark Fin DAB Car Antenna 75Ω Output Impedance

: Large Image : High Sensitive Shark Fin DAB Car Antenna 75Ω Output Impedance

Product Details:

Place of Origin:	CHINA
Brand Name:	CAZAN
Certification:	CE,ROHS
Model Number:	CAT-3003

Payment & Shipping Terms:

Minimum Order Quantity:	800pcs
Price:	negotiation
Packaging Details:	polybag or blister packing etc
Delivery Time:	20--35 WORK DAYS
Payment Terms:	T/T, L/C
Supply Ability:	19000pcs/ each month

Detailed Product Description

V.S.W.R:	≤2.0:1	Voltage:	DC10-14V
Installation:	Double Side Tape	Connector Type:	SMA Male Etc
Gain:	15dbi	Angle:	52°

high quality DAB car antenna with radio am fm UHF VHF antennae

ITEM NO.: CAT-3003

Product Description

DAB ANTENNA Specification

high quality am/fm radio DAB active car shark fin antenna

DAB Antenna	Working Frequency: 170MHz~240MHz (Band III) 1452MHz~1492MHz (L-Band) Output Gain: 15dB±3dB (Band Ⅲ) 12dB±3Db (L-Band) Output impedance: 75Ω V.S.W.R: ≤2.0:1 NOISE Figure: ≤2dB Working current: 30mA~60mA Rated voltage: DC 12V Rated Current: 40mA~50mA
AM FM Antenna	Frequency: 76-110MHz (FM), 525-1,700KHz (AM) Gain: +20dB (FM), +5dB (AM) Impedance: 75 ohm Cable: 3C-2V Voltage: 10-14V
Mechanical	Weight(gram)180 Cable: 5000mm etc. Connector: SMA,etc Mounting:double side tape Housing:Black
Environmental	Working Temp:-40℃~+85℃ Storage Temp:-45℃~+85℃ Vibration:Sine sweep1g(0-p)10~50~10Hz each axis Humidity:Humidity95%~100%RH Weatherproof:100%Waterproof(IP67)

We use are all new plastic, can resist ultraviolet ray and aging resistance, increase the service life of the antenna.Product is beautiful and clean without burr,.If you install the antenna, will make your car is very beautiful.

Quality assurance:

Warranty Duration: 1 years
Warranty Type: Manufacturer Warranty
